High frequency magnetic induction brazing stainless steel to steel process HLQ team was provided with 2 different parts to be brazed in our test laboratory. Objective:Ā Induction BrazingĀ of a 0.15āā/ 3.81mm stainless steel pin to a steel base. Equipment:Ā DW-UHF-6KW-III handheld induction brazing systemĀ Industry:Ā Appliances & HVAC Materials: Steel hexagon (base 1āā/ 25.4 mm diameter; 0.1āā/ … Read more
The Professional Induction Brazing Stainless Steel Tubing Joints Technology The goal of this induction brazing application test is for Induction Brazing Stainless Steel Tubing Joints evenly for increased repeatability. Industry:Ā Automotive Equipment:Ā DW-UHF-10KW induction brazing machine Time: 15 sec. Materials: Stay Silv Black Flux Temperature:Ā 1472Ā°FĀ (800Ā°C) Power: 8 kW Process: The two stainless tubes where … Read more
High frequency induction brazing automotive copper heating exchanger pipes A manufacturer of appliances wants to achieve automation in their induction brazing process. Their goal is to be able to induction brazing automotive copper heating exchanger pipes. We carried out several tests to choose the best induction heating products which can fit their needs. The HLQ … Read more
induction brazing copper and brass rods Objective Induction Brazing copper and brass rods and strips to replace torch operation. The current torch process results in excessive contaminants on the assembly, and requires extensive rework after the brazing operation. Equipment DW-UHF-40KW high frequency induction brazing machine Two turn open end conveyor coil Materials ā¢ Copper coupon … Read more
Induction Handheld Brazing Copper To Steel Tube Objective Braze copper cylinders, copper wires, and steel tubes in under 20 seconds using the DW-UHF-6KW-III handheld induction heating system. Equipment DW-UHF-6KW-III handheld induction heating system Test 1 Materials ā¢ Copper cylinder to copper wire. Power: 6.6kW Temperature: 871Ā° CĀ (1600Ā° F) Time: 20 sec Test 2 Materials ā¢ … Read more
Induction Brazing Copper T Pipe With Induction Heating Machine Objective Evaluate replacing of flame copper t pipe brazing with induction brazing. Equipment DW-HF-25kw high frequency induction heating machine Materials ā¢ Copper main tube ā 1.13ā (28.7 0mm) OD 1.01ā (25.65 mm) ID ā¢ Riser tube copper ā 0.84ā (21.33 0mm) Ā OD,Ā 0.76ā (19.30 0mm) Ā ID … Read more
High frequency induction brazing steel tube to steel fitting Objective Handheld high frequency induction brazing of a steel tube to a steel fitting Recommended Equipment The recommended equipment for this application is the DW-UHF-6KW-III handheld induction brazing heater heat station. Materials: Steel tube to steel fitting braze using Lucas-Milhaupt Easy FLO 3 brazing alloy ringsĀ and … Read more
Induction Brazing Carbide Onto Steel Part Objective Brazing carbide onto steel workpiece Equipment DW-UHF-6KW-III Handheld Induction Brazing Heater Key Parameters Power: 4kW Temperature: Approximately 1500Ā°F (815Ā°C) Time: 16 sec Materials Coil-Ā 2 helical turns (20 mm ID) 1 planar turn (40 mm OD, 13 mm Height) Carbide-Ā 13 mm OD,Ā 3 mm wall thickness Steel pieceā … Read more
Induction Brazing Copper Tube of Heat Exchanger Objective Brazing heat exchanger copper to copper pipes Industry Various industries Base material Copper tubes ā Diameter / thickness of external tube: 12.5 x 0.35 and 16.75 x 0.4 ā Type of assembly: lap joint Other materials Brazing alloy rings Equipment DW-UHF-6KW-III handheld induction brazing heater Key Parameters … Read more
Induction Brazing Aluminum to Aluminum Tube Objective Induction brazing of two aluminum pipes Equipment DW-UHF-6KW-III handheld induction brazing heater Materials Šluminum to aluminum tube Flared at interface 0.25ā (6.35mm) Brazed to steel tube 0.19ā OD (4.82mm) Power:Ā 6kW Temperature: 1600Ā°F (871Ā°C) Time:Ā 3sec Results and Conclusions: Induction heating provides: Strong durable joints Selective and precise heat zone, … Read more
