PWHT Chart Recorder
Category: PWHT Machine
Tags: PWHT chart, PWHT chart recorder, PWHT chart review, PWHT recorder, PWHT temperature chart
Description
Top MYD Series Post Weld Heat Treatment/PWHT Chart Recorder.
Many post weld heat treatment/PWHT process need temperature recorder. Our PWHT machines have six 6 channel paper recorder. Paperless recorder.
Table 12 DC Voltage and DC Current Input | ||
Type | Range | Accuracy (%) |
DC Voltage | (-1.00~1.00)V | ยฑ0.2 |
(-10.00~10.00)V | ยฑ0.05 | |
(-100.00~100.00)mV | ยฑ0.05 | |
(-20.00~20.00)mV | ยฑ0.05 | |
DC Current | (0.00~20.00)mA | ยฑ0.2 |
ย Table 16ย Analog Output | ||
Analog Output | Accuracy (%) | Load Capacity |
(0.00~20.00)mA | ยฑ0.2 | 550ฮฉ |
Table 14ย TC Input | ||
Type | Rangeย (โ) | Accuracyย (โ) |
B | 600~1800 | ยฑ2.4 |
E | -200~1000 | ยฑ2.4 |
J | -200~1200 | ยฑ2.4 |
K | -200~-100 | ยฑ3.3 |
-100~1300 | ยฑ2.0 | |
S | -50~100 | ยฑ3.7 |
100~300 | ยฑ2.0 | |
300~1600 | ยฑ1.5 | |
T | -200~-100 | ยฑ1.9 |
-100~380 | ยฑ1.6 | |
N | -200~1300 | ยฑ3.0 |
R | -50~100 | ยฑ3.7 |
100~300 | ยฑ2.0 | |
300~1600 | ยฑ1.5 | |
WRe5-26 | 0~2300 | ยฑ4.6 |
WRe3-25 | 0~2300 | ยฑ4.6 |
Note: The accuracy here excludes cold junction error. |
